Centrifugal
Vacuum Concentrator
Concenfuge 4/4R

  • Hits:168
  • Time:2024-4-7

Details


New electromagnetic drive system

high torque, low vibration, corrosion- resistant

Small volume & large capacity

Concentration of 264 pcs .5/2.0ml centrifuge tubes

in a single run

Large capacity design

24×50ml、10×100ml

chicken heart bottles、4×250ml(conical bottle)

Fast control system

More intelligent, accurate, efficient


Product Features

  • Built-in automated vacuum control system, control range 0.1~100mbar, control precision ±0.1mbar
  • 2-stage temperature control, protecting sample safety effectively
  • 4 groups program shortcut key, 30 groups user-defined programs
  • Centrifugal imaging function, observing concentration progress without power off the concentrator
  • Imported pressure relief valve with automatic vacuum release, safe and easy to operate
  • Corrosion-resistant vacuum design, unaffected by organic solvents


Technical Parameters

Technical Parameters

Concenfuge 4

Concenfuge 4R

Speed range

800rpm~2000rpm

800rpm~2000rpm

Max. Centrifugal force

650×g

650×g

Timing range

0~9999min

0~9999min

Sample chamber precooling function

N

Y

Centrifugal imaging function

Y

Y

Temperature control range

RT+5℃~+90℃

-5℃~+100℃

Temperature control precision

±1℃

±1℃

Ultimate vacuum

≤0.3mbar

≤0.3mbar

Noise

≤55dB(A)

≤60dB(A)

Power

750W

850W

Power supply

AC220V 50Hz/60Hz 10A

AC220V 50Hz/60Hz 10A

Dimension(L*D*H)

481×370×294mm

608×370×348mm

Weight

28.5KG

48.6KG
