General Features
Parameters |
Unit |
PiloFD8- 4.3V |
PiloFD8- 15.6V |
PiloFD8- 2001V |
PiloFD8- 4002V |
PiloFD8- 5003V |
|||
Nominal Area |
0.3 |
0.6 |
1 |
2 |
3 |
||||
Capacity |
Usable shelf area |
㎡ |
0.24 |
0.54 |
0.05 |
2.16 |
3.24 |
||
Condenser capacity |
Kg/B |
4 |
10 |
15 |
35 |
50 |
|||
Vial Qty. |
Ф16mm |
pcs |
900 |
2200 |
4265 |
9070 |
13608 |
||
Vial Qty. |
Ф22mm |
pcs |
460 |
1100 |
2268 |
4680 |
7020 |
||
Liquid capacity |
L |
4 |
10 |
15 |
35 |
50 |
|||
Basic Parameter |
Shelf dimension |
Width |
mm |
300 |
300 |
350 |
600 |
600 |
|
Length |
mm |
400 |
450 |
600 |
600 |
900 |
|||
Shelf distance |
mm |
100 |
90 |
||||||
Shelf qty. |
pcs |
2+1 |
4+1 |
5+1 |
6+1 |
6+1 |
|||
Shelf temp. range |
℃ |
-55~+80 |
|||||||
Shelf temp. difference |
℃ |
±1(in balance) |
|||||||
Min. Cold trap temp. |
℃ |
≤-75 |
|||||||
Vacuum leakage rate |
Pam³/sec |
≤5×10-3 |
|||||||
Ultimate pressure |
Pa |
≤1 |
|||||||
Basic Supply |
Cooling type |
Air-cooled, well- ventilated |
℃ |
≤25 |
|||||
Water-cooled, ≤30°C, 0.15~0.2MPa |
m³/hr |
0..3 |
0.6 |
0.9 |
2 |
4 |
|||
Installed power |
Kw |
3.3(single phase) |
5(three phase) |
8(three phase) |
16(three phase) |
21(three phase) |
|||
Total weight |
Kg |
510 |
820 |
1200 |
2000 |
2300 |
|||
Dimension |
Length |
mm |
700 |
900 |
1760 |
2200 |
2600 |
||
Width |
mm |
1300 |
1300 |
920 |
1400 |
1500 |
|||
Height |
mm |
1700 |
1800 |
2200 |
2100 |
2400 |
